IDC / Quick Disconnect Tab For #24-18 AWG Wire
Haben Sie Fragen zu diesem Produkt?
Weitere Informationen über diese Marke:
Zierick
Zierick
Packaging
- Loose
- Reeled
| Article Number | 1185 |
| Material Thickness / Type | 0.032" (0.81mm) C26000 Brass |
| Standard Finish | 100% Tin over Copper |
| Current Rating | 20 Amperes |
| Applicator System | Loose: WTP-4ALL Reeled: Model 9700, 9700 XY Wire Termination: Consult factory. |
| Mounting Type | Outward or Inward Splay |
| Mounting Hole Diameter | 2 x .058" ±0.003" (1.47mm ±0.076) holes on 0.20" (5.08mm) centers |
| Wire Gauge Range | #24-18 AWG |
| Pieces Per Reel (loose Part No.) | NA |
| Pieces Per Reel (reeled Part No.) | / |
| Datenblatt | Download Datenblatt |
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
