SMT Dual Entry Box Receptacle
Haben Sie Fragen zu diesem Produkt?
Weitere Informationen über diese Marke:
Zierick
Zierick
Packaging
- Loose
- Reeled
- Taped
| Article Number | 1266 |
| Mating Terminal Size | 0.020" (0.51mm) to 0.025" (0.64mm) thick |
| Material Thickness / Type | 0.008" (0.20mm) C51000 Phosphor Bronze |
| Standard Finish | 100% Tin over Copper |
| Current Rating Ul | 12 Amperes |
| Current Rating C-ul | 12 Amperes |
| Feeder System | Surf-Shooter SMT ™ Continuous Strip Feeder Standard 16mm Tape Feeder for PNs 1266-TV and 1266-TV-KT |
| Ul File Number | E361770 |
| Pieces Per Reel (loose Part No.) | NA |
| Pieces Per Reel (reeled Part No.) | / |
| Pieces Per Reel (taped Part No.) | / |
| Datenblatt | Download Datenblatt |
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
