SMT Vertical or Horizontal Box Receptacles
Haben Sie Fragen zu diesem Produkt?
Weitere Informationen über diese Marke:
Zierick
Zierick
Packaging
- Loose
- Small reeled
- Taped
- reeled
| Article Number | 1277 |
| Mating Terminal Size | 0.025" (0.64mm) square or round pin |
| Material Thickness / Type | .008" (0.20mm) C51000 Phosphor Bronze |
| Standard Finish | 100% Tin over Copper |
| Current Rating Ul | 10 Amperes |
| Current Rating C-ul | 10 Amperes |
| Feeder System | Loose: Standard 16mm Tape Feeder for PN 1277-TH Standard 24mm Tape Feeder for PN 1277-TV-G Standard 16mm Tape Feeder for PN 1277-TV-N Reeled: Consult Factory for Feeder |
| Ul File Number | E361770 |
| Pieces Per Reel (loose Part No.) | NA |
| Pieces Per Reel (reeled Part No.) | / |
| Pieces Per Reel (taped Part No.) | / |
| Pieces Per Reel (small Reel Part No.) | / |
| Datenblatt | Download Datenblatt |
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
