SMT Tabs / Quick Disconnect Terminals 0.250" (6.35mm)
Haben Sie Fragen zu diesem Produkt?
Weitere Informationen über diese Marke:
Zierick
Zierick
Packaging
- Loose
- Reeled
- Small reeled
- Taped
| Article Number | 1285 |
| Extra Description | SMT |
| Hole Dimension | 0.070" (1.78mm) hole |
| Material Thickness / Type | 0.032" (0.81mm) C26000 Brass |
| Standard Finish | 100% Tin over Copper |
| Current Rating Ul | 25 Amperes |
| Feeder System | Surf-Shooter SMT ™ Continuous Strip Feeder for PN 6285 Standard 24mm Tape Feeder for PN 1285TG |
| Ul File Number | E146208 |
| Pieces Per Reel (loose Part No.) | NA |
| Pieces Per Reel (reeled Part No.) | / |
| Pieces Per Reel (taped Part No.) | / |
| Pieces Per Reel (small Reel Part No.) | / |
| Datenblatt | Download Datenblatt |
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
