Female round connector

Plastic nut + plastic body

RDJ - RDJF 00410 126

RDJ - RDJF 00410 126

Haben Sie Fragen zu diesem Produkt?

Kontaktieren Sie unseren Steckverbinderspezialist

Schick mir ein individuelles Angebot

Download Datenblatt

Weitere Informationen über diese Marke:

Number Of Poles

4
5

Article Number	RDJF 00410 126
Number Of Contacts	4
Protection Degree	IP67*
Upper Temperature	+90 °C
Lower Temperature	-25 °C
Cable Diameter	Double cable 2,1-3 4-5 mm
Fixing Thread	M12
Housing Material	Plastic
Housing Oil Resistance	Very good
Contact Material	Optalloy
Max. Wire Section	0,75 mm²
Locking Nut Material	Plastic
Voltage Vdc	1 to 250
Voltage Vac	1 to 250
Max. Currrent	4 A @40°C
Contact Gender	F
Coding	A
Cabling System	Screw vite
Remark	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart

Article Number	RDJF 00510 096	RDJF 00510 126
Number Of Contacts	5	5
Protection Degree	IP67*	IP67*
Upper Temperature	+90 °C	+90 °C
Lower Temperature	-25 °C	-25 °C
Cable Diameter	6-8 mm	Double cable 2,1-3 4-5 mm
Fixing Thread	M12	M12
Housing Material	Plastic	Plastic
Housing Oil Resistance	Very good	Very good
Contact Material	Optalloy	Optalloy
Max. Wire Section	0,75 mm²	0,75 mm²
Locking Nut Material	Plastic	Plastic
Voltage Vdc	1 to 60	1 to 60
Voltage Vac	1 to 60	1 to 60
Max. Currrent	4 A @40°C	4 A @40°C
Contact Gender	F	F
Coding	A	A
Cabling System	Screw vite	Screw vite
Remark	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart

Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
