IP54 piercing clip terminal block
Haben Sie Fragen zu diesem Produkt?
Weitere Informationen über diese Marke:
Techno
Techno
Number Of Poles
- 2
- 3
| Article Number | THP.112.A2A |
| Number Of Contacts | 2 |
| Protection Degree | IP54 |
| Upper Temperature | +125 °C |
| Lower Temperature | -40 °C |
| Rated Voltage | 450 |
| Pollution Degree | 2 |
| Rated Current | 17.5 A |
| Contact Terminal | Pin - piercing clip terminals / Piercing crimp terminals |
| Terminals | Piercing / crimp |
| Cable Section | 0,5 -1,5 mm² |
| T Marking | T125 °C |
| Impulse Withstand Category | III |
| Impulse Withstand Voltage | 6 kV |
| Tracking Index | PTI 250 |
| Terminal Block Housing | PA66 GF UL94 V0 GWT 960°C black |
| Grommets | TPE |
| Contact Screw Terminals | Brass nickel plated |
| Standard / Piercing Screws | M3 steel zinc brass plated |
| Standards | EN61984:2001 |
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
