Inserts 6+PE
Do you have any questions about this product?
More info on this brand:
Hummel
Hummel
Contacts
- Without
- dip solder length 10 mm
- dip solder length 17 mm
- without (RAL2003 insert)
| Number Of Contacts | 6+PE |
| Termination | Crimp/dip-solder (PCB) |
| Wire Section | 0,34-1,5 mm² |
| Upper Temperature | +125 °C |
| Lower Temperature | -40 °C |
| Max. Contact Resistance | 3 mΩ |
| Material | Thermoplastic Polyamid PA 6/Fire protection class V-0 |
| Required Crimp Contacts | |
| Contact Diameter (mm) | 1,25 |
| Nominal Current | 16 A |
| Nominal Voltage (degree Of Pollution 3) | 630 V ~ |
| Test Voltage | 2500 V ~ |
| Insulation Resistance | >1010 MΩ |
Characteristics differ between variants of a connector
