Female cable connector

Do you have any questions about this product?

More info on this brand:

Article Number	99 0686 19 03
Connector Diameter	20.2 mm
Number Of Contacts	2+PE contacts
Connector Locking System	Screw (M12-S)
Termination	Screw clamp with insulated ferules
Wire Section	2.5 mm²
Protection Degree	IP67
Mating Cycles	>50 times
Upper Temperature	+85 °C
Lower Temperature	-40 °C
Rated Voltage	630
Rated Impuls Voltage	6000 V
Pollution Degree	3
Overvoltage Categorie	III
Material Group	III
Rated Current (40°)	16 A
Max. Contact Resistance	3 mΩ
Material Of Contact	CuSn (Bronze)
Plating	Au (Gold)
Material Of Insert	PA
Material Of Housing	PA
Cable Outlet
Product sheet	Download product sheet

Article Number	99 0690 19 04
Connector Diameter	20.2 mm
Number Of Contacts	3+PE contacts
Connector Locking System	Screw (M12-S)
Termination	Screw clamp with insulated ferules
Wire Section	1.5 mm²
Protection Degree	IP67
Mating Cycles	>50 times
Upper Temperature	+85 °C
Lower Temperature	-40 °C
Rated Voltage	630
Rated Impuls Voltage	6000 V
Pollution Degree	3
Overvoltage Categorie	III
Material Group	III
Rated Current (40°)	12 A
Max. Contact Resistance	3 mΩ
Material Of Contact	CuSn (Bronze)
Plating	Au (Gold)
Material Of Insert	PA
Material Of Housing	PA
Cable Outlet	8-10 mm
Product sheet	Download product sheet

Characteristics differ between variants of a connector
