Receptacle Contact AWG 18 to 14
Do you have any questions about this product?
More info on this brand:
JST
JST
Applicable Wire
- AWG 18 to 14
| Article Number | SRWF-61GG-M0.6 |
| Upper Temperature | +85 °C |
| Lower Temperature | -25 °C |
| General Description | Disconnectable Crimp Style |
| Applicable Wire Size | 0.75 to 2.0 (AWG #18 to #14) mm² |
| Connection Type | Wire to Wire Connectors |
| Rated Current (ac/dc) | Power/15 Signl/2.0 A |
| Rated Voltage (ac/dc) | Signl/50 Power/250 V |
Characteristics differ between variants of a connector
This connector is a hybrid type double-row drawer connector with combined signal and power supply circuits to connect the units. In the signal part, the number of parts reduced by connecting the crimping contact directly.
Space saving
Panel locking device
Hybrid type
Standards
UL Recognized E60389
CSA Certified LR20812
TUV Certified J50102230
RoHS Compliant
