IP20 insert power socket connector
Do you have any questions about this product?
More info on this brand:
Techno
Techno
Number Of Poles
- 2
- 3
- 5
- 6
| Article Number | THB.388.B2A | THP.388.B2A |
| Number Of Contacts | 2 | 2 |
| Protection Degree | IP20 | IP20 |
| Upper Temperature | +125 °C | +125 °C |
| Lower Temperature | -40 °C | -40 °C |
| Rated Voltage | 400 | 400 |
| Pollution Degree | 2 | 2 |
| Rated Current | 25 A | 17.5 A |
| Contact Terminal | Contact screw terminals. For cable section < 1.0 mm² | Piercing clip terminal max 1,5 mm² |
| Terminals | Screw | Piercing |
| Cable Section | max 4,0 mm² | 0,5 - 1,5 mm² |
| Min-max Cable Diameter | max 17,0 mm | max 17,0 mm |
| T Marking | T125 °C | T125 °C |
| Impulse Withstand Category | II | II |
| Impulse Withstand Voltage | 4 kV | 4 kV |
| Tracking Index | PTI 175 | PTI 175 |
| Connector Housing | PA66 UL94 V0/V2 GWT 850°C black - grey RAL 7035 | PA66 UL94 V0/V2 GWT 850°C black - grey RAL 7035 |
| Terminal Block Housing | PA66 GF UL94 V0 GWT 960°C black - grey RAL 7035 | PA66 GF UL94 V0 GWT 960°C black - grey RAL 7035 |
| Contact Screw Terminals | Brass nickel plated OR Brass silver plated (THX.388.XXX.AG) | Brass nickel plated OR Brass silver plated (THX.388.XXX.AG) |
| Standard / Piercing Screws | M3 steel zinc plated | M3 steel zinc brass plated |
| Standards | EN61984:2001 | EN61984:2001 |
Characteristics differ between variants of a connector
