Style A square connector

  • Current amplifier + yellow Led
Télécharger la fiche produit

Housing Material

  • PUR
Article Number CA53 83A2T 507 3000 0
Protection Degree IP67
Upper Temperature +70 °C
Lower Temperature -5 °C
Circuits Current amplifier + yellow Led
Housing Oil Resistance Very good
Housing Hardness 90 shore A
Other Characteristics M3 central screw material: zinc plated iron
Voltage Vdc 10 to 30
Max. Currrent 3 A @40°C
Control Voltage 10..30 Vdc
Control Current 1mA @ 10V 3MA @ 30V A
Les propriétés diffèrent selon les variantes et sous-variantes
