Female round connector

Avez-vous des questions sur ce produit?

Télécharger la fiche produit

Plus d’infos sur cette marque:

Article Number	REJF 00310 070	REJF 00311 070
Number Of Contacts	3	3
Protection Degree	IP67*	IP67*
Upper Temperature	+90 °C	+90 °C
Lower Temperature	-25 °C	-25 °C
Cable Diameter	3,5-5 mm	3,5-5 mm
Housing Material	PA66 30%GF	PA66 30%GF
Housing Oil Resistance	Very good	Very good
Contact Material	Golden over nickel plated CuZn	Golden over nickel plated CuZn
Max. Wire Section	0,5 mm²	0,25 mm²
Locking Nut Material	Metal nickel plated	Metal nickel plated
Voltage Vdc	1 to 60	1 to 60
Voltage Vac	1 to 60	1 to 60
Max. Currrent	3 A @40°C	3 A @40°C
Contact Gender	F	F
Ground Pole	No	No
Max. Number Wires	3	3
Coding	A	A
Cabling System	Screw vite	Solder
Remark*	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart

Article Number	REJF 00410 070	REJF 00411 070
Number Of Contacts	4	4
Protection Degree	IP67*	IP67*
Upper Temperature	+90 °C	+90 °C
Lower Temperature	-25 °C	-25 °C
Cable Diameter	3,5-5 mm	3,5-5 mm
Housing Material	PA66 30%GF	PA66 30%GF
Housing Oil Resistance	Very good	Very good
Contact Material	Golden over nickel plated CuZn	Golden over nickel plated CuZn
Max. Wire Section	0,5 mm²	0,25 mm²
Locking Nut Material	Metal nickel plated	Metal nickel plated
Voltage Vdc	1 to 30	1 to 30
Voltage Vac	1 to 30	1 to 30
Max. Currrent	3 A @40°C	3 A @40°C
Contact Gender	F	F
Ground Pole	No	No
Max. Number Wires	4	4
Coding	A	A
Cabling System	Screw vite	Solder
Remark*	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart	The protection degree level is guaranteed only when correctly assembled with Shield's couterpart

Les propriétés diffèrent selon les variantes et sous-variantes
