Provertha
Number Of Poles
- 15
| Article Number | 118150DC25000 | 118151DC25000 |
| Number Of Contacts | 15 | 15 |
| Upper Temperature | +85 °C | +85 °C |
| Lower Temperature | -25 °C | -25 °C |
| Thread | UNC 4-40 | M3 |
| Material | zn alloy | zn alloy |
| Extra Information | Extend installation space for big cable diameter, mixed layout D-Sub, EMC electronic housing Simple assembly by only a few single parts and pre-assembled locking screws | Extend installation space for big cable diameter, mixed layout D-Sub, EMC electronic housing Simple assembly by only a few single parts and pre-assembled locking screws |
| Locking Style | knurled screw | knurled screw |
| Cable Exit | Straight 180° Angled: 1x90° | Straight 180° Angled: 1x90° |
| Cable Fixing | Cable clamp extern (al) crimping flange | Cable clamp extern (al) crimping flange |
| Cable Outputs | 2 | 2 |
| Cable Diameter External Cable Clamp | 4-14 | 4-14 |
| Cable Diameter Crimping Flange | 3,7-8,7 | 3,7-8,7 |
| Material/surface Locking Screws Diecast | ST tin plated | ST tin plated |
| Material/surface Cover Screws | ST Zinc plated | ST Zinc plated |
Eigenschappen verschillen tussen varianten en subvarianten
