Higo
Number Of Poles
- 4
| Article Number | 5300.1010 |
| Color | Blue |
| Connector Diameter | 9 mm |
| Cable Length | 200 mm |
| Protection Degree | IP66 |
| Mating Cycles | 200 times |
| Upper Temperature | 80 °C |
| Lower Temperature | -25 °C |
| Rated Voltage | 48 V AC / 60 V DC |
| Max. Contact Resistance | ≤10 mΩ |
| Material Of Contact | Copper Alloy |
| Remark | Specs above are related to the Mini B connector Other cable length/type on request |
| Rated Current | 4 A |
| Max. Insulation Resistance | ≥20 MΩ |
| Contact Plating | Gold over Nickel |
Eigenschappen verschillen tussen varianten en subvarianten
