Connectoren
Terug naar productoverzicht
Binder
Number Of Poles
- 3
- 5
- 8
- 12
| Article Number | 79 9149 020 03 |
| Connector Diameter | 16 mm |
| Number Of Contacts | 3 contacts |
| Connector Locking System | Snap-in |
| Termination | Moulded |
| Wire Section | 0.75 mm² |
| Cable Length | 2 mm |
| Protection Degree | IP67 |
| Mating Cycles | >500 times |
| Upper Temperature | +70 °C |
| Lower Temperature | -40 °C |
| Rated Voltage | 250 |
| Rated Impuls Voltage | 2500 V |
| Pollution Degree | 2 |
| Overvoltage Categorie | II |
| Material Group | II |
| Rated Current (40°) | 7 A |
| Max. Contact Resistance | 3 mΩ |
| Material Of Contact | CuSn (Bronze) |
| Plating | Au (Gold) |
| Material Of Insert | PA (UL 94 V-0) |
| Material Of Housing | PUR |
| Cable Diameter | 6,9 mm |
| Product sheet | Download product sheet |
Eigenschappen verschillen tussen varianten en subvarianten
