Connectoren
Terug naar productoverzicht
Number Of Poles
- 6 (2+4)
Article Number | F618AG A 00 GN 1000 |
Color | Black |
Connector Diameter | 18 mm |
Wire Section | 2 x 3,3 + 4 x 0,2 mm² |
Cable Length | 1000 mm |
Protection Degree | IP67 |
Mating Cycles | 3000 times |
Upper Temperature | 80 °C |
Lower Temperature | -25 °C |
Rated Voltage | 48 V AC / 60 V DC |
Max. Contact Resistance | ≤10 mΩ |
Material Of Contact | Copper alloy |
Cable Diameter | 8 mm |
Insulation Wire | FEP |
Remark | Other cable length/type on request |
Rated Current | 30 / 2 A |
Max. Insulation Resistance | ≥20 MΩ |
Contact Plating | Silver plated |
Fitting Length | 20 mm |
Material Jacket | PVC |
Eigenschappen verschillen tussen varianten en subvarianten
