Connectors with ferrite plates dip solder 90° version
Meer info over dit merk:
Provertha
Number Of Poles
- 9
- 15
- 25
- 37
Article Number | FP 09 156 G.TR4B | FP 09 166 G.TR4B |
Number Of Contacts | 9 | 9 |
Upper Temperature | +85 °C | +85 °C |
Lower Temperature | -25 °C | -25 °C |
Rated Voltage | 100 | 100 |
Remark | For the requested quality class please replace the "." at the end of the article no. By using 1,2,3 | For the requested quality class please replace the "." at the end of the article no. By using 1,2,3 |
Remark ** | For the requested Thread type please replace the "4" (standard) at the end of the article no. By using 3 or 4 | For the requested Thread type please replace the "4" (standard) at the end of the article no. By using 3 or 4 |
Insulation Resistance | 1 MΩ | 1 MΩ |
Extra Information | The economical EMC solution for low loss | The economical EMC solution for low loss |
Thread Type | 3 = M3 4= UNC-4-40 | 3 = M3 4= UNC-4-40 |
Current Rating | Max. 5 | Max. 5 |
Gender | Male | Female |
Test Voltage U Eff | 200 | 200 |
Quality Class* | Class 1 = 500 mating cycles Class 2 = 200 mating cycles Class 3 = 50 mating cycles | Class 1 = 500 mating cycles Class 2 = 200 mating cycles Class 3 = 50 mating cycles |
Capacitor Values**** | 01 = 2000 pF 02= 1000 pF 03= 500 pF 04= 250 pF 05= 120 pF 06= 43 pF 07= 22 pF 08= 15 pF 09 = 2 pF (available for non-filters pins) 10 = customized types | 01 = 2000 pF 02= 1000 pF 03= 500 pF 04= 250 pF 05= 120 pF 06= 43 pF 07= 22 pF 08= 15 pF 09 = 2 pF (available for non-filters pins) 10 = customized types |
Eigenschappen verschillen tussen varianten en subvarianten
