Number Of Poles
- 8 (2+1+5)
Article Number | S828BG A 00 CD 1000 |
Color | Black/Purple |
Connector Diameter | 28 mm |
Wire Section | 2 x 10AWG+ 1 x 18AWG + 5 x 22AWG mm² |
Cable Length | 1000 mm |
Protection Degree | IP67 |
Mating Cycles | 3000 times |
Upper Temperature | 80 °C |
Lower Temperature | -25 °C |
Rated Voltage | 48 V AC / 60 V DC |
Max. Contact Resistance | ≤10 mΩ |
Material Of Contact | Copper alloy |
Cable Diameter | 10 mm |
Insulation Wire | Teflon |
Remark | Other cable length/type on request |
Rated Current | 50 / 15 / 2 A |
Max. Insulation Resistance | ≥20 MΩ |
Contact Plating | Silver plated |
Fitting Length | 50 mm |
Material Jacket | PVC |
Eigenschappen verschillen tussen varianten en subvarianten
